Semi-Automatic Brick Shape Rice Vacuum Packing Machine
Contacter le Fournisseur
Attributs du Produit
- Personnalisation
- Disponible
- Service après-vente
- soutien pour vidéo en ligne ou service de site
- Garantie
- 1 an
- N° de Modèle.
- DCS-5F80N
- Demande
- Nourriture, riz, céréales, noix, haricots, litière pour chat
- Puissance
- Pneumatique
- Automatisation
- Semi-automatique
- Dispositif gonflable
- Avec dispositif gonflable
- Type
- machine de remplissage et d'étanchéité
- Etat de l'objet
- Poudreux, granules, granulés, poudre
- État
- Nouveau
- personnalisation
- disponible
- rapport de test des machines
- fourni
- vidéo-inspection-sortie
- fourni
- alimentation
- ac380v
- Paquet de Transport
- caisse en bois exportée
- Spécifications
- 2050*1370*2453mm
- Marque Déposée
- élevé fait
- Origine
- Zhangzhou, China
- Code SH
- 8422303090
- Capacité de Production
- 1200 jeux / année
Images du produit de Semi-Automatic Brick Shape Rice Vacuum Packing Machine
-
Semi-Automatic Brick Shape Rice Vacuum Packing Machine -
Semi-Automatic Brick Shape Rice Vacuum Packing Machine -
Semi-Automatic Brick Shape Rice Vacuum Packing Machine -
Semi-Automatic Brick Shape Rice Vacuum Packing Machine -
Semi-Automatic Brick Shape Rice Vacuum Packing Machine -
Semi-Automatic Brick Shape Rice Vacuum Packing Machine -
Semi-Automatic Brick Shape Rice Vacuum Packing Machine
Trouver des Produits Similaires
Description de Produit
Packaging application scope:
It is suitable for vacuum packaging of granular materials in fields such as rice, grains, seeds, nuts, beans, cat litter, and pet feeds, etc.
Performance characteristics
1. Manual bagging, realize automatic weighing, automatic detection, automatic filling, automatic vacuum, automatic shaping, automatic sealing, automatic output of finished products function.
2. The first industry four measuring scales, double stations, small specifications (1.25kg or less) packaging using dual-tube filling technology, four packages at a time, faster, more efficient, and can realize the small specifications of the material 1500 packages / hour.
3. Adopting double touch screen, double vacuum pump, more humanized design, more flexible use, more simple operation.
4. Adopting international famous electrical components, more stable and reliable performance.
5. Adopting high-precision vibration control technology, fast speed and high precision.
Specification
Packaging Range | 0.3-5 kg |
Specifications | 2050*1370*2453mm |
Packaging Speed | 700-1400 bags / hour |
Packaging Accuracy | +/- 0.2g |
Power Supply | AC380V, 4KW |
Shipping and packaging | Exported Wooden Case |
Customization | Available |
Fujian High-Made Intelligent Equipment Manufacturing Co., Ltd. China's first manufacturer of six-sided vacuum equipment specializes in the core technology and R&D for the intelligent vacuum packing machine.
Our main products are brick-shaped and flat-shaped vacuum packing machines, which range from full-auto to semi-auto. Apply to vacuum, shaping, and fresh-keeping for small granules like rice,nut,grains, cat litter, beans, peanuts, etc. We can also provide complete design, production, and installation services for automatic production lines, according to customer requirements. Maintain leadership in industry influence.
With more than ten years of development, we have always focused on product quality and technology innovation, and have a professional talent group that has worked for a long time on the vacuum, shaping, and automatic packing system. Hide-Made packing machines have grown much more stable and efficient. Won the title of national high-tech enterprise, science & technology little giant leading enterprise, and the third prize of innovation competition in Fujian province. Gold award of the International Grain Oil Products and Equipment Technology Exhibition.
Now our business has expanded to 32 provincial administrative regions and exported to Europe, the Americas, Southeast Asia, the Middle East and other regions worldwide. As an important strategic partner with famous domestic industries such as Cofco, Yihai Kerry, Beidahuang Group, etc.
For the future, we will always adhere to the concept of quality, innovation, and service. Strictly implement the ISO9001-2015 quality management system to form a production management model with lean production, standardized management, and specialized services. Build a perfect service network among pre-sale, in-sale, and after-sale. We will keep improving and forge ahead based on our technology advantages to provide better and more reliable products and services to our customers. And looking forward to building a win-win business relationship with you!
Our main products are brick-shaped and flat-shaped vacuum packing machines, which range from full-auto to semi-auto. Apply to vacuum, shaping, and fresh-keeping for small granules like rice,nut,grains, cat litter, beans, peanuts, etc. We can also provide complete design, production, and installation services for automatic production lines, according to customer requirements. Maintain leadership in industry influence.
With more than ten years of development, we have always focused on product quality and technology innovation, and have a professional talent group that has worked for a long time on the vacuum, shaping, and automatic packing system. Hide-Made packing machines have grown much more stable and efficient. Won the title of national high-tech enterprise, science & technology little giant leading enterprise, and the third prize of innovation competition in Fujian province. Gold award of the International Grain Oil Products and Equipment Technology Exhibition.
Now our business has expanded to 32 provincial administrative regions and exported to Europe, the Americas, Southeast Asia, the Middle East and other regions worldwide. As an important strategic partner with famous domestic industries such as Cofco, Yihai Kerry, Beidahuang Group, etc.
For the future, we will always adhere to the concept of quality, innovation, and service. Strictly implement the ISO9001-2015 quality management system to form a production management model with lean production, standardized management, and specialized services. Build a perfect service network among pre-sale, in-sale, and after-sale. We will keep improving and forge ahead based on our technology advantages to provide better and more reliable products and services to our customers. And looking forward to building a win-win business relationship with you!
Q: What is the maximum output capacity for small specification materials (≤1.25kg)?
A: Our dual-workstation vacuum packaging machine can reach up to 2000 bags per hour for small-size packaging. It applies dual pipe filling technology to produce four bags simultaneously.
Q: Can the two workstations run independently?
A: Yes. The dual-workstation design supports separate operation.You may run one workstation only for lower volume production,which brings higher flexibility.
Q: What automatic functions does the machine have? Is manual operation required?
A: Manual bag loading is required. The machine completes automatic weighing, detection, filling, vacuuming, shaping, bag sealing and finished product output automatically.
Q: What electrical configuration and protection level does the machine adopt?
A: It is equipped with double touch screens and well-known international electrical parts. All circuit cables are protected with bellows, and the electric control cabinet reaches IP44 protection grade for stable and safe operation.
Q: What kinds of materials are suitable for this vacuum packaging machine?
A: It is ideal for granular materials such as rice, beans, nuts, cat litter and other small-particle bulk goods, especially for small specification packaging within 1.25kg.
A: Our dual-workstation vacuum packaging machine can reach up to 2000 bags per hour for small-size packaging. It applies dual pipe filling technology to produce four bags simultaneously.
Q: Can the two workstations run independently?
A: Yes. The dual-workstation design supports separate operation.You may run one workstation only for lower volume production,which brings higher flexibility.
Q: What automatic functions does the machine have? Is manual operation required?
A: Manual bag loading is required. The machine completes automatic weighing, detection, filling, vacuuming, shaping, bag sealing and finished product output automatically.
Q: What electrical configuration and protection level does the machine adopt?
A: It is equipped with double touch screens and well-known international electrical parts. All circuit cables are protected with bellows, and the electric control cabinet reaches IP44 protection grade for stable and safe operation.
Q: What kinds of materials are suitable for this vacuum packaging machine?
A: It is ideal for granular materials such as rice, beans, nuts, cat litter and other small-particle bulk goods, especially for small specification packaging within 1.25kg.
À propos du fournisseur
Ce fournisseur a été audité par SGS. Vérifiez le rapport sur le site officiel de SGS avec l'identifiant "QIP-ASI267374". Les éléments marqués "
" sont certifiés.
Profil de l'Entreprise
Fujian High-Made Intelligent Equipment Manufacturing Co., Ltd est une entreprise nationale de haute technologie dédiée à la recherche et au développement, à la production, à la vente, au service après-vente de machines d'emballage intelligentes et à la ligne de production automatique.
Nos produits comprennent principalement des unités d'assemblage d'emballages quantitatifs automatiques, des unités d'assemblage d'emballages de mise en forme automatique sous vide et des équipements de support pour les lignes de production automatiques. Nos fournissent principalement des services quantitatifs, de vide, de façonnage et de préservation pour les matériaux granulaires dans des industries telles que les céréales, les aliments, les aliments pour animaux, les produits chimiques et les animaux de compagnie. Nous fournissons également à nos clients des services complets de conception, de production et d'installation pour les lignes de production d'emballages automatisés en fonction de leurs besoins.
Nos produits sont exportés vers l'Asie du Sud-est, le Moyen-Orient et d'autres pays, et nous sommes des partenaires stratégiques importants pour des entreprises nationales bien connues. Comme le Groupe COFCO, le Groupe Yihai Kerry et le Groupe Beidahuang.
Notre entreprise continuera à fournir aux utilisateurs, au pays et à l'étranger, des produits de meilleure qualité et plus fiables, ainsi que des services plus parfaits et professionnels, pour réaliser avec vous une entreprise gagnant-gagnant.
À propos de notre Usine & Contexte Commercial
-
Type d'Entreprise
- Fabricant/Usine & Société Commerciale
- Adresse
- No. 1-3 Shunda Road, Gunong Farm, Changtai District, Zhangzhou, Fujian, China
-
Surface de l'Usine
- 30140 Mètres Carrés
-
Nombre d'Employés
- 105
-
Capital Social
- 32,000,000 RMB
-
Conditions de Paiement
- LC, T/T
-
Conditions Commerciales Internationales(Incoterms)
- CIF, CFR, EXW
-
Délai Moyen
- Délai de Livraison en Pleine Saison: Un Mois, Délai de Livraison hors Saison, Un Mois
-
Port le plus Proche
- Xiamen Port
-
Quantité minimum de commande
- 1 set
-
Partenaires de la chaîne d'achat
- 70
Notre Capacité de Production & Expertise Technique
-
Produits Principaux
- Machine de conditionnement sous vide en forme de brique, machine de conditionnement en sac tissé PP/sac PE, machine de conditionnement sous vide en forme d'oreiller, machine d'encaissement automatique, machine de conditionnement en sac extérieur automatique, balance de conditionnement avec pesée
-
Lignes de production
- 4
-
Machines de production
- Press Machine, Punching machine
-
Inspecteurs QA/QC
- 3 people
-
Type d'inspection pour les produits finis
- 100% inspection(Inspection visuelle & Contrôle de fonctionnement)
-
Méthode d'inspection des produits finis
- Avoir des instructions et les suivre uniformément
-
Options de personnalisation
- Personnalisation à partir des conceptions, Personnalisation Complète, Personnalisation mineure, Personnalisation flexible
-
Service ODM disponible
- Oui
-
Service OEM disponible
- Oui
-
Ingénieurs R&D
- 18 people
-
Traçabilité des matières premières
- Oui
-
Marque Propre
- Oui
Notre expérience dans le Secteur & Record Commercial Mondial
-
Année de Création
- 2020-06-29
-
Année d'Exportation
- 6 years
-
Principaux Marchés
- Europe, Asie du Sud-Est/Moyen-Orient
-
Répéter le choix des acheteurs
- 30%~50%
-
Nombre d'Employés du Commerce Extérieur
- 4
-
Agent/Succursale à l'Étranger
- Non
-
Nouveaux produits lancés l'année dernière
- Oui
Nos Certifications, Normes & Reconnaissance de l'Industrie
-
Certification du Système de Gestion
- ISO9001:2015, ISO45001:2018, ISO14001
-
Certification du produit
- Autres
-
Coopéré avec Fortune 500
- Non
