Power Relay Single Phase Secondary Injection Tester Testing System for Protection
Contact Supplier
Product Highlights
- High Accuracy Measurement: Output precision of 0.5 degree for current and voltage with measurement accuracy under 0.1ms.
- Six-Phase Output Capability: Simultaneously outputs six-phase current and voltage, capable of 180A parallel current.
- Independent Host Operation: Embedded IPC with 300-600MHz frequency, 128M memory, and Windows XP OS for standalone use.
- Durable Stainless Steel Design: Features imported stainless steel panel, keypad, and touch-pad mouse for enhanced durability.
- GPS Synchronous Testing: Enables synchronous testing across different locations via embedded synchronization card and RS232.
- Auto-Regulation Software: Software-based auto-regulation eliminates manual potentiometer calibration for improved stability.
- Flexible PC Connectivity: Direct USB access to PC without patch cords; runs on notebook with same software.
- Comprehensive DC Output: Includes independent DC auxiliary voltage source with 110V and 220V outputs for relay testing.
Product Attributes
- Customization
- Available
- After-sales Service
- Life Long Support
- Warranty
- Support
- Model NO.
- HMJBC-702
- Type
- Strength Testing Machine
- Maxcapacity
- No
- Accuracy Grade
- 0.5
- Load Way
- Electronic Load
- Loading Method
- Dynamic Load
- Display
- LCD
- Control
- Computer Control
- Weight
- 28kg
- Power Source
- AC220V
- Oil Cylinder Position
- No
- Time Measuring Range
- 0.1ms - 9999s
- Accuracy of Measurement
- <0.1ms
- Phase Voltage / Line Phase Output Power
- 70va / 140va
- Harmonic Time
- 1-20
- Frequency Range (Fundamental)
- 20-1000Hz
- Output Precision
- 0.5 Degree
- Product Name
- Production Relay Tester
- Work Temperature
- -10°C~ 50°C
- Transport Package
- Wooden Box with Foam Inside
- Specification
- customize
- Trademark
- GDHM
- Origin
- Hubei, China(Mainland)
- HS Code
- 9030820000
- Production Capacity
- 200sets/Month
- Package Size
- 48.00cm * 35.00cm * 20.00cm
- Package Gross Weight
- 28.000kg
Shipping
Online Trading Protection
- Payment Guarantee
-
Platform-protected payments with refund support for eligible order issues.
- Platform Logistics
- Clearer shipment tracking with platform-supported logistics.
- Inspection Service
- Optional pre-shipment inspection for quality and quantity checks.
- After-Sales & Dispute Handling
- Platform-assisted dispute resolution, including refunds or returns when applicable.
Only orders placed and paid through Made-in-China.com Secured Trading are eligible for payment protection and the corresponding platform services.
Product Images of Power Relay Single Phase Secondary Injection Tester Testing System for Protection
-
Power Relay Single Phase Secondary Injection Tester Testing System for Protection -
Power Relay Single Phase Secondary Injection Tester Testing System for Protection -
Power Relay Single Phase Secondary Injection Tester Testing System for Protection -
Power Relay Single Phase Secondary Injection Tester Testing System for Protection -
Power Relay Single Phase Secondary Injection Tester Testing System for Protection -
Power Relay Single Phase Secondary Injection Tester Testing System for Protection -
Power Relay Single Phase Secondary Injection Tester Testing System for Protection
Find Similar Products
Product Description
High Accuracy 3 three Phase Wholesale Price optical digital Microcomputer Secondary Current Injection Test Set/ Protection Relay Test set for power disctribution cabinet
Advantage
1.It satisfies all requirements of field test.
The tester can simultaneously output standard six-phase current and six-phase voltage with 30A/phase current and 125V/phase voltage. Connecting six phase current in parallel can acquire 180A current. The tester can not only test traditional relays and protective devices, but also test modern microcomputer-based protective devices, especially the differential protection of transformers and automatic switching devices of stand-by power supply. Testing becomes more convenient and perfect.
2. All technical parameters meet the criteria DL/T624-1997 Technical Specifications of Test Equipment Based on Micro-computer for Relaying Protection issued by the Ministry of Electric Power Industry.
3. The host machine, which has embedded high performance IPC (industrial personal computer), can run independently with its 300-600MHz main frequency, 128M memory, 6-12G hard disk and Windows XP operating system.
4. It was the first one in the industry to apply imported stainless steel panel, stainless steel keypad, touch-pad mouse, which overcomes such defects of trackball mouse as difficulty in operating and prone to damage. The TFT true color display is employed with a size of 8.4 inch and its resolution being 800×600. Consequently, the overall operation of the host machine becomes convenient and durable.
5. The main control board is of DSP+FPGA structure, outputting 16 bit DAC, which may generate 2000 points high density sine wave per week to fundamental wave, greatly ameliorate the quality of waveform and improve the accuracy of tester.
6. The power amplifier is hi-fi linear type, which can both guarantee the precision of low current and the stability of heavy current.
7. The device can directly access to PC machine through USB interface, needless of any patch cord.
8. The device can run by access to notebook computer, which is installed with a same software, needless to relearn how to operate.
9. The device has GPS synchronous testing function with embedded synchronization card (matching), which accesses to PC machine through RS232 interface, so the synchronous testing by exchanging two testers in different places can be achieved.
10. The tester is equipped with independent special DC with auxiliary voltage source output, whose output voltages are 110V (1A), 220V (0.6A), for the purpose of meeting the power need of DC relay or protective devices.
11. The tester has the function of auto-regulation by software, avoiding the calibration accuracy by opening cabinet to regulate potentiometer, so the stability of accuracy is greatly improved.
3 phase micro computer protection relay test set
Specification
AC current output
| Phase current output (effective value) | 0~40A |
| Output Precision | 0.5degree |
| 3 phase parallel current output (effective value) | 0~120A |
| A Long-time Phase current | 10A |
| Maximum output power of Phase current | 450VA |
| Maximum output power of 3 parallel current | 900VA |
| Maximum Permitted work time of 3 parallel current | 10S |
| Frequency range ( fundamental) | 20~1000Hz |
| Harmonic time | 2~20 |
DC current output
| Current output | 0~±10A / phase, 0~±30A / 3 parallel |
| Output Precision | 0.5 degree |
AC voltage output
| Phase voltage output (effective value) | 0~120V |
| Output Precision | 0.5 degree |
| Line voltage output (effective value) | 0~240V |
| Phase voltage / Line phase output power | 80VA / 100VA |
| Frequency range (fundamental) | 20~1000Hz |
| Harmonic time | 1~20 |
DC voltage output
| Phase voltage output range | 0~±160V |
| Output Precision | 0.5 degree |
| Line voltage output range | 0~±320V |
| Phase voltage / Line phase output power | 70VA / 140VA |
10 path digital input and 8 path digital output
| Time measuring range | 0.1ms ~ 9999s |
| accuracy of measurement | <0.1ms |
