Basic Features | |
Laser Wavelength | 1535±5nm |
Eye-safe Class | Class 1(IEC 60825-1) |
Laser Divergence Angle | 0.6mrad |
Rangefinding Performance | ≥3000M(2.3m×2.3m Target board orVehicle Reflectance 30%,Relative Humidity≤60%,Visibility≥10Km) ≥1500M(0.5m×1.7mTarget board or Human target,Reflectance30%,Relative Humidity≤60%,Visibility≥10Km) ≥800M(0.2m×0.3m target,Reflectance 30%,Relative Humidity≤60%,Visibility≥10Km) |
Measurement Frequency | 1~10Hz(Measurement frequency of sample: 1 Hz) |
Measuring Accuracy | ±1M |
Blind Area | 10M |
resolution ratio | 1M |
Emitting Aperture | Ø7.9mm |
Receiver Aperture | Ø15X10mm |
Detection Probability | ≥98% |
False Alarm Rate | ≤1% |
Electrical Characteristics | |
Communication Interface | UART (TTL_3.3V)Compatible with 5.0V |
Baud Rate(bps) | 9600/14400/19200/38400/57600/115200 (default)/128000/230400 |
Operating Voltage | DC3.3-5V |
Power Consumption | ≤1W@1Hz ≤1.5W@10Hz |
Physical Characteristics | |
Weight | 18±0.5g |
Dimensions | <28×24.6×14.3mm |
Optional | Plastic Bracket Version Metal Bracket Version |
Eco-friendly | RoHS |
Environment Adaptability | |
Operating Temperature | -40~+60°C |
Storage Temperature | -40~+70°C 10%~95%RH |
